AVC-D20-PCLXR-09X
Interchangeable boring heads carrying 80° rhombic inserts.
Price: Log in For Price
Toote spetsifikatsioonid
| Functional Length (LF) | 26 mm | Application | | Int. 80° Diamond 95° Approach | |
| Functional Width (WF) | 13 mm | Rake Angle Axial (GAMP) | -5 Degrees |
| Connection Diameter Machine Side (DCONMS) | 20 mm | Rake Angle Radial (GAMF) | -10 Degrees |
| Inscribed Circle Diameter (IC) | 9.35 mm | Body Material | Steel |
| Minimum Bore Diameter (DMIN) | 25 mm | Measurement Type | Metric |
| Cutting Direction (HAND) | Right Hand | Unit | M |
Toote omadused
| FamilyDesc | Interchangeable boring heads carrying 80° rhombic inserts. | FamilyName | AVC-PCLXR/L |
| COO | Israel | BrandName | Iscar |
Shipping Info
PackageWeight
0.0530
Name
General Indexable Turning Tools
FamilyName
AVC-PCLXR/L
BrandName
Iscar
