Toote spetsifikatsioonid
| Type | Vertical Machining Center | Y-Axis | 600 mm |
| Controller | Fanuc 0i-MF (10.4 inch)/ OPT Heidenhein TNC-620 (15 inch) | Z-Axis | 560 mm |
| Table Width/Diameter | 520 mm | Coolant Capacity | 270 L |
| Table Length | 1120 mm | Tool Storage Capacity | 30 (opt. 40) |
| Spindle Taper | BBT-40 | Operating Dimensions | 3363 × 2812 mm |
| Spindle Speeds | 12000 (Opt. 15000) rpm | Model No | P106 |
| Horsepower | 23 (excl. CTS) kVA | Table Load | 600 kg |
| Phase | 3 | Weight | 6450 kg |
| X-Axis | 1060 mm |
Toote omadused
| Remarks | ⦁ X-travel 760/1060/1360 mm for Vc-P76/P106/P136 ⦁ High rapid feeds 48/48/32 m/min (P76/P106) ⦁ 12000rpm spindle output 18.5 KW(S3) ⦁ BBT-40 / 30 tools ⦁ Roller guideways ⦁ Bottom guarding flush (P106 only) ⦁ Screw chip removers ⦁ Electrical counterbalance |
Shipping Info
PackageWeight
0
Related Documentation
X-travel 760/1060/1360 mm for Vc-P76/P106/P136High rapid feeds 48/48/32 m/min (P76/P106)12000rpm spindle output 18.5 KW(S3)BBT-40 / 30 toolsRoller guidewaysBottom guarding flush (P106 only)Screw chip removersElectrical counterbalance
