Toote spetsifikatsioonid
| Type | Permanent Lift Magnets | Magnet Height | 216 mm |
| Load Capacity | 500 kg | Material | Neodymium |
| Maximum Rated Flat Capacity | 500 kg | Model No | TML 500 |
| Magnet Length | 295 mm | Weight | 7.3 kg |
| Magnet Width | 118 mm | Minimum Material Thickness for Activation | 2 mm |
Toote omadused
| FamilyDesc | Lifting magnets for flat steel products | Remarks | ■ Up to 490 kg (1100 lbs) load-bearing capacity from a material thickness of 10 mm (3/8″) and 300 kg (660 lbs) from just 5 mm (3/16″) material thickness on steel S235 plus 3:1 safety factor (i.e. the force which leads to the breakaway of the metal sheet must represent triple the maximum holding force) ■ Outstanding performance on thin-walled materials (useable from as low as 2 mm (1/16″) ■ Up to 70 % less dead weight with at least the same performance in contrast to conventional magnets ■ Easy activation with minimal effort due to the ergonomic activation lever ■ Innovative operational concept allowing for an enlarged operating range ■ 360° rotatable and 180° pivotable load swivel ■ Wear-resistant magnetic contact area made of hardened steel with TiN-coating preventing damages and guaranteeing a long lifetime |
